Primoco One 150 UAV, Czech Republic

Primoco One 150 unmanned aircraft can be equipped with a range of sensors for reconnaissance applications.
The One 150 is medium-sized UAV designed and developed by Primoco UAV. Credit: Primoco UAV SE.
The One 150 UAV has fully autonomous take-off and landing capabilities. Credit: Primoco UAV SE.
The One 150 UAV can be fitted with a ballistic rescue parachute for emergency landing in populated areas in case of failure. Credit: Primoco UAV SE.

The Primoco One 150 is a medium-sized, fully-autonomous unmanned aerial vehicle (UAV) designed and developed by Primoco UAV for civilian and military surveillance operations. Primoco UAV is a vehicle manufacturer based in Czech Republic.

The UAV is compliant with European Union Aviation Safety Agency (EASA) Specific Operations Risk Assessment (SORA) and STANAG 4703. SORA is a standard of risk assessment for UAVs. The company was approved as a development and production organisation according to the latest European Military Airworthiness Requirements (EMAR) 21 standard, in 2020.

Primoco UAV and Swiss company UMS Skeldar formed a partnership to provide a combination of the Primoco One 150 fixed-wing and UMS Skeldar’s V-150 rotary-wing UAVs to select customers. Presented to select customers in November 2021, the two UAVs can be controlled by a single ground control system as both the UAVs share the same communication datalink.

Primoco One 150 UAV testing

The military version of the UAV, Primoco UAV One 150M, underwent successful flight testing on 30 September 2020. The UAV was tested for military compliance in presence of members from the Department of Supervision of Military Aviation of the Ministry of Defence of the Czech Republic and the Military Technical Institute of Aviation and Air Defence.

It was tested by Primoco UAV and the Czech Army at the military training area Libavá earlier in that month. The testing focused on evaluating the performance of the UAV’s battlefield communication systems and optical reconnaissance sensors. It proved the ability of the Primoco One 150 UAV to operate as a vital part of the manned network concept and enable the Czech Army to deploy a secure communications system in different areas including challenging terrain conditions.

Primoco One 150 UAV design and features

Primoco One 150 UAV features a fully composite airframe. The aircraft is designed to provide autonomous operations during take-off, flight, and landing. It is also capable of operating during day and night and in challenging weather conditions. The design offers versatility to customise the aircraft to suit multiple mission requirements of the customers.

The unmanned aircraft’s ability to take off from runways with a length of 300m allows customers to undertake missions from remote locations. The One 150 also offers easy maintenance and low operating costs.

The UAV has a maximum take-off weight of 150kg. It has a length of 3.65m, a height of 1.25m, and a wingspan of 4.85m. The payload carrying capacity is 30kg with a mixed sensor payload.

The platform can be shipped in a container measuring 2.9m long, 1.2m wide, and 1m deep.

Communication systems and sensors aboard Primoco One 150 UAV

The One 150M can be equipped with military communication systems and an electro-optical reconnaissance system. It features a radio station from L3Harris and ANW2C datalinks from Persistent Systems.

The unmanned aircraft also features a gimbal-mounted Epsilon 180 full HD electro-optical (EO)/middle wavelength infrared (MWIR) observation unit, SD thermal imaging channel in MWIR band and a laser rangefinder. The thermal imaging sensor enables high-quality reconnaissance at night. The EO/IR system leverages autonomous technology to enable automatic object tracking. The aircraft uses a 5GHz to 6GHz radio datalink or Inmarsat satellite communication. It can be integrated with light detection and ranging (LIDAR) sensors and other customised sensors.

The remotely piloted aircraft system (RPAS) can be mounted with the TK-7 optical multispectral sensor, which will enable autonomous search and evaluation of ground-based objects.

The One 150 is also integrated with NSP-3, NSP-5, and NSP-7 synthetic aperture radars installed on the portside of the fuselage to enable the detection of targets and points of interest in low visibility areas and to determine the speed of the moving targets in both land and maritime target modes.

PT-8 and PT-8N automatic optical scanning systems are provided as optional sensors to locate the ships and survivors on the water surface. The NSP-7 radar has different modes of scanning including Ku band Strip mode, ground moving target indication (GMTI), spotlight, and coherent change detection (CCD).

Navigation and control system on Primoco One 150 UAV

Primoco One 150 is equipped with a Glonass/Galileo/Beidou global positioning system (GPS). The onboard inertial unit acts as an independent navigation system.

The UAV will have a full-fledged automatic dependent surveillance-broadcast (ADSB)-in/out transponder and an up to Mode 5 military identification friend or foe (IFF) identifier capability, which are expected to improve unmanned and manned co-ordination in the same airspace.

It is equipped with the VECTOR autopilot system, TELEM5 datalink with 900MHz frequency, GCS03 ground control station, and VisionAir mission planning and interface programme.

The aircraft can be remote controlled throughout its journey from take-off to landing. It is equipped with an emergency parachute for landing in case of failure.

Engine and performance of Primoco One 150 UAV

The unmanned vehicle is powered by an in-house Primoco 340 four-stroke, four-cylinder, fuel injection piston engine. The air-cooled Primoco 340 engine has a weight of 15kg and a rated power output of 25hp.

The UAV has an endurance of 15 hours and a maximum range of 2,000km. It has a service ceiling of approximately 3,300m and a cruising speed range between 100km/h and 150km/h.
