The Infotron IT180-3EL-I mini UAV has been in service with the French Army since 2012. Image: courtesy of ECA Group.

IT180-3EL-I UAV features three-blade contra-rotating rotors. Image: courtesy of ECA Group.

The IT180-3EL-I unmanned aerial vehicle can fly at a maximum altitude of 3km. Image: courtesy of ECA Group.

Infotron IT180-3EL-I is a mini-vertical take-off and landing (VTOL) unmanned aerial vehicle (UAV) designed for military and homeland security operations.

It has been in service with the French Army since 2012.

The UAV is intended to perform missions such as intelligence, surveillance, target acquisition and reconnaissance (ISTAR), search and rescue, damage assessment, port and coastal protection, force protection, battlefield management, as well as covert operations.

With the ability to locate, identify and track hostile threats and offending operators, the system provides warfighters with high survivability and improved situational awareness on the battlefield.

The VTOL UAV was displayed during SITDEF 2015 exhibition in Bangkok in November 2015. It was presented to foreign law enforcement agencies in October 2015 in France.

Design and features of IT180-3EL-I aerial vehicle

IT180-3EL-I is based on IT180 mini UAV developed by Infotron, which was acquired by ECA Group, a subsidiary of France-based Gorgé Group engaged in the design and manufacture of UAVs in April 2014.

The mini VTOL UAV, designed according to military standards, is equipped with a patented three-blade contra-rotating rotors with a rotor diameter of 1.8m. It has a total mass of 21kg when unloaded.

The drone can be integrated with payloads of up to 3kg on the top and/or beneath. It is easy to use and can be deployed in less than six minutes. It features autonomous take-off and landing capabilities, and has the ability to perform missions using an autopilot.

Payloads carried on IT180-3EL-I UAV

The drone is equipped with a gyro-stabilised, pan/tilt/zoom electro-optical / infrared (EO/IR) video camera for capturing high-resolution imagery and video in both day and night conditions.

The EO/IR camera has capabilities such as geo-location, geo-tracking, target acquisition and laser pointer, as well as continuous 360° pan or tilt rotation.

In day mode, the camera produces images with a resolution of 820px x 530px using 36x zoom lens. It can detect, recognise and identify human threats at distances of up to 1km, 600m and 300m respectively.

In night mode, the camera can detect, recognise and identify objects at ranges of 800m, 150m and 70m respectively using 8x zoom lens.

The unmanned air system employs a long-range secure data link to transmit information collected by payloads to the ground control station.

Ground control station

The VTOL UAV and its payloads are operated manually by personnel from the associated ground control station (GCS) using a joystick. The GCS transmits mission planning and command and control signals to the UAV through the data link.

Propulsion and performance of IT180-3EL-I UAV

Powered by a two-stroke, 46cm³ brushless DC electrical engine, the IT180-3EL-I mini UAV can attain a maximum speed of 80km/h. The engine offers endurance of up to 50 minutes in flight mode and ten minutes of flight time in perch mode.

The UAV can fly at a maximum altitude of 3,000m and withstand wind speeds of 60km/h. It has a data link range of up to 10km. Its flexible architecture provides increased stability under extremely harsh weather conditions. The noise level of the IT180-3EL-I is 44dBA at 100m above ground level.
