Agni-V Long Range Ballistic Missile (LRBM), India




Key Data


Agni-V long range ballistic missile launch

Agni-V is a long range ballistic missile (LRBM) being developed indigenously by the Defence Research and Development Organisation (DRDO) of India. It is the first long-range intercontinental ballistic missile of India and is said to be capable of carrying a nuclear warhead. The missile has a range of 5,000km.

Agni-V was successfully test-fired from a test range at Wheeler Island, off the coast of Orissa in eastern India, in April 2012. It was launched from Launch Complex 4 of the Integrated Test Range (ITR) using a rail mobile launcher.

With the successful launch of Agni-V, India has joined the elite club of nations such as the US, Russia, China, France and the UK which possess LRBM capability. Though the official range of the missile is 5,000km, China has claimed that the Indian missile has a range of 8,000km.

Agni-V is expected to enter service with the Indian Army by 2014-15. Agni-V belongs to the Agni (meaning 'fire' in Hindi) class of missiles.

Development of India's Agni long range missile programme

"With the successful launch of Agni-V, India has joined the elite club of nations such as the US, Russia, China, France and the UK which possess LRBM capability."

Development of Agni-V LRBM began in 2008. Although developed as an extension to the Agni-III intermediate-range ballistic missile, Agni-V is an entirely new design developed using inputs from Agni-III.

Agni-V is a three-stage solid-propellant missile. The first stage was adapted from Agni-III. Two stages of this missile were made of composite material. About 60% of the sub-systems used in Agni-V are similar to those of Agni-III.

Remaining systems, including the Ring Laser Gyro based inertial navigation system (INS) and accelerometer, were developed using advanced technologies. Research Centre Imarat (RCI), a wing of DRDO, supplied gyroscope technology which was proved successful with Agni-III and Shourya missiles.

The three solid-propellant composite rocket motor stages of the missile were independently tested by mid-2011. During the first launch, Agni-V's flight time lasted 20 minutes and the third stage fired the re-entry vehicle. The re-entry vehicle hit the pre-designated target located more than 5,000km away from the launch site. The ships deployed at midrange and target point tracked the missile's trajectory.

The intercontinental missile has a length of 17.5m and a diameter of two metres. The launch weight of the missile is 50t. It can carry a payload of more than 1,000kg. The missile has a range of 5,000km, which can be further increased by reducing the payload.

Multiple independent re-entry vehicles (MIRVs) and warhead details

Agni-V is attached with multiple independent re-entry vehicles (MIRVs). MIRVs can carry three to ten independent nuclear warheads.

"Agni-V is a canister-launched, road-mobile missile similar to the Dongfeng-31A of China."

Each warhead can be assigned to engage different targets located hundreds of kilometres away from each other.

Two or more warheads can also be assigned to a single target for better strike impact.

MIRVs provide a second strike capability against hard targets. MIRV warheads are also equipped with electronic equipment for jamming hostile radars. The interception of multiple warheads is much harder than killing a single warhead.

Propulsion of the Agni-V LRBM

Agni-V is powered by three solid fuelled engines. It uses a composite case solid rocket motor for the third stage. The first stage engine propels the missile up to 40km height. The second and third stages take it into 150km and 300km of height respectively. The missile finally reaches 800km and re-enters the Earth's atmosphere to fly towards the target.

Launch platform used for the DRDO's long range ballistic missile

Agni-V is a canister-launched, road-mobile missile similar to the Dongfeng-31A of China. The launch platform is the 8 x 8 Tatra TELAR (transporter erector launcher) rail mobile launcher.

The canister is made of maraging steel and provides a completely airtight atmosphere to preserve the missile for years. The canister is designed to withstand 300 to 400t of thrust generated at the time of missile launch.

Navigation systems aboard the Indian Agni-V missile

Agni-V is equipped with a Ring Laser Gyro based inertial navigation system (INS) and the modern micro navigation system (MINS). The navigation system, the onboard high speed computer and the fault tolerant software were all developed indigenously.


The Global Missiles and Missile Defence Systems Market 2011-2021

This project forms part of our recent analysis and forecasts of the global missiles and missile defence systems market available from our business information platform Strategic Defence Intelligence. For more information click here or contact us: EMEA: +44 20 7936 6783; Americas: +1 415 439 4914; Asia Pacific: +61 2 9947 9709 or via email.

Agni-V is a long range ballistic missile (LRBM) being developed by DRDO of India.
Agni-V was successfully test-fired in April 2012.
The 8 x 8 Tatra TELAR rail mobile launcher is the launch platform of the missile.
Agni-V's flight time lasted 20 minutes.
