Black Scorpion Police APC

Carat Security Group

black scorpion

The Carat Defense Toyota Police APC is the ideal low-cost platform for police action in urban and off-road environments. With a high level of armoured protection and enhanced capabilities over rough terrain, the P-APC is the ultimate law enforcement tool.

The world-renowned reliability of the Toyota HZJ79, combined with a modern electronics and armor package, providesthe ultimate security when law enforcement officials are in harm's way.

Protection level: assault rifle

The armored monocoque hull is fabricated from high-hardness armour steel providing protection for occupants and critical components from ballistic and blast threats including DM51 grenades and anti-personnel mines.

Standard features

  • Protection level: Assault rifle STANAG -1
  • Steering version: LHD
  • Multi-layered ballistic glass
  • Engine & Battery protection
  • Runflat system
  • Protected fuel tank
  • Fuel tank capacity: 180l
  • Individual rear seats
  • Intercom system
  • Siren
  • Public address
  • Left side door
  • Air conditioning

Optional features



  • Intercom system
  • Flagstaff
  • Electric winch
  • Roof hatch
  • Strobe flashlights
  • Light bars
  • Screen and windows mesh protection
  • Rear door leg protection
  • PC board
  • Inside cubicle
  • Provision formilitaryradioHF/VHF/UHF
  • Provision for jamming system (ECM)
  • Provisions for smoke and tear gas grenades launchers

Base vehicle

  • Toyota HZJ79 -6-cylinder diesel, 4.164cc turbocharged, intercooled
  • Engine: maximum power -138 kW (180hp) -maximum torque 365Nm at 2250rpm
  • Measurements: L5560 x W2136 x H2233mm -wheelbase: 3180mm / weight: 4200kg
