Aqeri

Rugged Military Computers, Communications Equipment and Peripherals

Aqeri

Aqeri is a leading Swedish producer of computers and communication equipment for extreme environments. Our customers often demand tailor-made solutions with specifications that are unique to their application.

With our knowledge based on more than 25 years of experience in the industry we have specialised in delivering solutions that meet the needs of our customers in the shortest time possible. Our product range covers everything from fully rugged computers in the smallest form factor to rack mounted servers.

We have a tool box of tested, verified and field proven hardware building blocks that we use when developing new products.

We develop climate control units, cooling and heating systems, ruggedised power supply solutions as well as the right choice of interface connectors. These components are included in every Aqeri product.

Our electronic solutions in combination with the protection of our in-house designed rugged mechanics results in products that will survive in any environment.

Aqeri mini-series half 19in - rugged 4G router

The Aqeri 86102 4G Router allows you to access and share your 4G LTE or 3G mobile broadband connections. Once connected, you can transfer data, stream media, and send SMS messages.

The DWR-921 utilises dual-active rewalls (SPI and NAT) to prevent potential unwanted intrusions WPA / WPA2 wireless encryption keeps your wireless network secure.

The Aqeri 86102 4G Router comes in a small form factor chassis, ideal for space critical environments such as installation in vehicles. It can be mounted in a 19in rack single or together in pairs, as well as stand alone or on a wall.

This is a mini Router ideal for harsh environments.

Mounting: Stand alone, 19in rack single or together in pairs, wall mount.

Other products in the Aqeri mini-series include:

  • Aqeri 85001, rugged mini NAS
  • Aqeri 88001, rugged mini video matrix
  • Aqeri 86302, rugged mini VoIP
  • Aqeri 86101, rugged mini router

Small mobile rugged computers and routers for the battlefield

The Aqeri 91022 mobile rugged computer is a small form factor product designed to be deployed in areas with the harshest environments and space critical demands. A typical scenario is deployed vehicles where space and weight is critical.

The Aqeri 91022 rugged computer can be mounted stand-alone or as an option in 19in racks. Aqeri 91022 has the latest high-performance Intel processor, 2nd generation Core i7 Quad Core and is expandable with up to two SSD drives in a RAID configuration for mission critical data.

As a standard the Aqeri field proven ASCC functions (Aqeri Supervisor and Climate Control) is implemented. The Aqeri 91022 has designed filtering to comply with MIL-STD-461E Army Ground levels.

As an option Aqeri 91022 can be ordered as a TEMPEST SDIP-27 Level A certified product to comply with NATO compromising emanations standards.

The Aqeri 96102 mobile rugged router and integrated Ethernet switch is based on the Cisco 5915 embedded service router. The router has integrated Ethernet switching function and Aqeri field proven ASCC functions (Aqeri Supervisor and Climate Control).

Rugged computers 19in

The Aqeri 9102 is a rugged computer, 19in slim line 2U, for use in harsh environments. Its small dimensions and front accessibility make it suitable for space-critical applications.

The chassis is fully sealed for protection against dust and corrosive elements. Cooling is provided by a heat exchanger cooling system. A fully aluminum construction ensures low radiation and high noise immunity in accordance with MIL-STD-461D standards.

The Aqeri 91050-01 is a rugged computer, 19in 5U, for use in harsh environments.

Its unique cooling system makes it possible to use a Xeon processor with very high performance and high-end PCI express graphics from Nvidia. The chassis is fully sealed for protection against dust and corrosive elements.

Both models feature a fully aluminum frame which ensures low radiation and high noise immunity in accordance with MIL-STD-461D standards.

The rugged design of the 9102 and 91050-01 provides total protection against shock and vibration.

Military rugged routers

The Aqeri 98211 is a military rugged router based on the Cisco 2821-HSEC/9. The unit is equipped with Cisco modules for Ethernet, FXO / FXS, V35, ISDN etc.

The Aqeri 98211 has internal climate control for use in a wide temperature area and a temperature monitoring port for alarm output. Furthermore, it has an internal redundant AC power unit and a 24VDC outlet for driving external equipment.

Rugged military IP phones

The Aqeri 96400 is a rugged IP phone specially designed for military applications, which delivers the latest advancements in IP telephony.

It provides communication over the same data network as your computer, allowing you to place and receive phone calls, put calls on hold, transfer calls, and make conference calls. The Aqeri 96400 is built into a fully sealed and vibration-proof aluminum chassis.

Computer peripherals for harsh environments

The Aqeri 9315 includes a 15in LCD monitor, an 83-key keyboard and a pointing device. The 9315 occupies only two height units when folded into a rack, making it suitable for space critical applications.

Both the monitor and the keyboard units are fully sealed for protection against dust and corrosive elements. A fully aluminum construction ensures low radiation and high noise immunity (according to MIL-STD-461D).

The rugged design gives protection against shocks and vibration. An internal heating and climate control system makes the unit usable in extremely low temperature environments.

The 92230 is a ruggedised military 23in widescreen monitor made for use in harsh environments. It is a flexible device that can be used for mobile and stationary applications.

In the back it features VGA (DB15 HD) and DC in (three-pin military connector, cannon type). The monitor is made for wall mount, console mount or freestanding version.

Proven performance through testing

To ensure durability of the product, thorough tests are carried out where the capacity is tested under harsh conditions. We have an EMC chamber for testing electromagnetic interference and a climatic chamber where we perform rigorous testing in extreme heat, cold and moisture.

Our own test facility is also equipped with equipment for shock and vibration control. All our processes are quality assured in accordance with ISO 9001:2008.

Contact Details

Aqeri
Domnarvsgatan 7
163 53 Spånga
Sweden
+46-8-564 737 30
+46-8-761 29 25
info@aqeri.com
sales@aqeri.com
www.aqeri.com

Available White Papers

Download

Small Form Factor, High Performance, Rugged IT Equipment for Battlefield Deployment 23 August 2016 There are many challenges when it comes to the deployment and use of IT equipment in the forefront of military missions.
